liquid Crystal Digital Display Universal Testing Machine

  • It's mainly used in the tensile testing of metal materials with obvious yield phenomenon.

  • Control method of rate testing: manual control

SHARE:

  • Main Function and Usage


    • It is mainly used in the tensile testing of metal materials with obvious yield phenomenon.

    • Control method of rate testing: manual control.

    • It can be used in testing  the tensile strength, yield strength, percentage elongation after fracture and other mechanical performance index of the metal materials.


    Main Specifications and Technical Parameter


     ModelWE-2000DWE-1000DWE-600DWE-600BWE-300B
    Maximum Testing Force2000kN1000 kN600kN600kN300kN
    Class of Testing MachineClass 1
    Efficient Measure Range10%-100%FS
    Relative Accuracy of Value Display±1%
    Tensile Volume（mm）1300700650650650
    Compression Volume（mm）1000550550550600
    Column Space（mm）745550450430430
    Round Specimen Clamping Range（mm）Φ20-Φ65Φ6-Φ45Φ6-Φ40Φ6-Φ40Φ6-Φ26
    Flat Specimen Clamping Thickness（mm）0-500-300-300-300-30

    Max. Width of

    Flat Specimen Clamping（mm）

    		14075757575
    Pressure Plate Dimension（mm）Φ300Φ160Φ160Φ160Φ160
    Overall Dimension（L*W*H）(mm)1200*800*3300910*830*2300840*700*2200740*590*2150
    Oil Source Console Dimension（mm）700*700*1500
    Total Motor Power（kW）42221.5
    Total Weight（kg）90003200230020001600
